POJAČALO 100V RCF AM2160, 160W
ZVUČNIK Power Dyn PDS40W 100V VISILICA 952.512
ZVUČNIK STROPNI RCF PL60
AM21601
AM21602
AM21601
AM21602

POJAČALO 100V RCF AM2160, 160W

160W- 100V pojačalo klase D sa integrisanom miksetom koja ima 4 ulaza, sa mogućnošću phantom power napajanja.

Add to Wishlist
Kategorije: ,
  • Opis
  • Brand

Opis

  • Full digital technology Mixer Amplifier 160 W RMS
  • 100 V – 70 V and 4 Ohm outputs
  • 4 universal inputs with phantom facility on screw terminal connections
  • Presence Control and per-channel High-Pass filters
  • XLR connector on input 1
  • RJ45 connectors on input 2 and 3 for connection to BM3001 microphone
  • Configurable Priority settings, VOX facility on input 1
  • Selectable aux inputs with two keys on the front panel for music source
  • Aux inputs with volume and tone controls
  • Music On Hold and PRE outputs
AM 2160 is a mixer-amplifiers with 4 mic-line audio inputs on removable connectors (the first input also has an XLR socket) and 2 aux inputs for music sources (e.g. CD players, tuners, etc.). 160 W nominal output power available either for low impedance loudspeakers or 100 – 70 V constant voltage line.
SPECIFICATIONS
Amplifier specifications
AMPLIFIER CLASS:
D
NUMBER OF CHANNELS:
1
POWER OUTPUT PER CHANNEL (@ 4 OHM):
160 W RMS
POWER OUTPUT (HI-Z):
160 W RMS
FREQUENCY RESPONSE (-3DB):
50 Hz ÷ 14 kHz
DISTORTION (THD+N) @ 1 KHZ NOMINAL POWER:
<0.3 %%
Input section
BALANCED:
7
GENERAL PURPOSE INPUTS (GPI):
2
LINE CONNECTORS:
RCA
LINE INPUTS:
2
MIC+LINE CONNECTORS:
Euroblock, XLR
MIC+LINE INPUTS:
4
MIC+LINE PHANTOM:
32 V DC
VOX: (MIC+LINE):
Yes
MONO:
7
PAGING COMMAND:
Contact
PAGING CONNECTORS:
RJ45
PAGING INPUTS:
2
STEREO:
2
TOTAL NUMBER OF INPUTS:
8
UNBALANCED:
2
Output section
SIGNAL OUTPUT NUMBER:
2
SIGNAL OUTPUT CONNECTORS:
RCA
POWER OUTPUT CONNECTORS:
Euroblock
Processing
TONE CONTROLS:
Yes
HIGH-PASS FILTER:
150 Hz
Controls
CONFIGURATION:
DIP switch, Front panel
PRIORITY:
Yes
MUSIC ON HOLD:
Yes
CHIME TONE:
Yes
Protections
COOLING:
Convection
SHORT CIRCUIT:
Yes
THERMAL:
Yes
DC DELAY:
Yes
FUSES:
Yes
Power requirement
OPERATING VOLTAGE:
220-240/115 V~ 50/60HzV ~ Hz
VOLTAGE SELECTION:
Internal
POWER CONSUMPTION:
350 W
Standard compliance
CE MARKING:
Yes
Physical specifications
CABINET/CASE MATERIAL:
Metal
COLOR:
Black
RACK MOUNTING:
19″, 2U
Size
DEPTH:
230 mm / 9.06 inches
HEIGHT:
88 mm / 3.46 inches
WEIGHT:
5.4 kg / 11.9 lbs
WIDTH:
442 mm / 17.4 inches
Shipping informations
PACKAGE DEPTH:
330 mm / 12.99 inches
PACKAGE HEIGHT:
200 mm / 7.87 inches
PACKAGE WEIGHT:
6.45 kg / 14.22 lbs
PACKAGE WIDTH:
500 mm / 19.69 inches

Brand

RCF

RCF je renomirani italijanski brend audio opreme, osnovan 1949. godine u Italiji. Lider je na tržištu live PA uređaja i zvučnika a pored njih, proizvode i pojačala, komercijalna i kućna audio rješenja, miksete, evakuacione sisteme, konferencijske sisteme... Amedex D.O.O. je ovlašteni distributer za RCF proizvode za Bosnu i Hercegovinu.
